Aurubis BARS&PROFILES
Aurubis BARS & PROFILES provides copper solutions for electrical power systems as well as generators, substations, distribution systems, switchgear, and conductor systems. We provide copper products for medical systems and different areas of research that use electricity to create magnetic fields. Other applications include AC and DC motors as well as induction furnaces in which metals are heated for smelting.
Basis for sophisticated applications
Aurubis FOXROD copper rod from our own production is used as a preliminary product for Aurubis BARS&PROFILES. This rod is processed into bars and profiles with the help of a continuous extrusion process.
The products have excellent properties for applications in a variety of sectors. These properties include high electrical conductivity and high copper content of at least 99.9 %. Our copper profiles also feature smooth surfaces and the tightest of tolerances. The profiles can be processed by bending and coating.
Extrusion tools give each bar and profile its shape. Because our tools are produced in-house, throughput times can be kept very short from the first drawing to the manufactured profile, even with new profiles. Complex profiles with maximum cross-sections up to 2000 mm2.
Production capacity
>
per year
More than
>
new product developments per year
Aurubis BARS&PROFILES
>
available profiles
Generation and distribution of energy
- Aurubis BARS&PROFILES provides copper solutions for use in generators and is used to produce electricity
- Electricity is distributed via switchgear and substations as well as conductor and distribution systems
- This allows Aurubis BARS&PROFILES to make a direct contribution to the distribution of electricity
High-energy systems
- Aurubis BARS&PROFILES provides copper products for high-energy applications
- Medical systems and other research areas in which electricity is used to generate magnetic fields
- Induction furnaces in which magnetic fields are used for metal melts
- Other applications in which electricity is used for lighting or converted into mechanical energy or heat
Product portfolio
Our copper products are available in different versions. The cross-sectional areas of the products can range from 20 mm2 (180 g/m) to 3,000 mm2 (27 kg/m).
The standard packaging for our copper products is a (sandwich-type) wooden box that ranges from 4,000 mm to 6,000 mm in length. In addition, some products can be delivered on loose coils weighing up to 1,800 kg.
Additional packaging options are available upon request.
Aurubis BARS&PROFILES provides a wide range of flat bars for processing in the electrical engineering industry. With lengths up to 10 m, widths from 10 mm to 50 mm, and heights from 2 mm to 50 mm, flat bars can be manufactured as finished products according to customer specifications.
Additional dimensions and custom-made products available upon request.
Round bars are also some of the most popular Aurubis BARS&PROFILES products. With lengths up to 10 m and diameters between 12 mm and 52 mm, round bars can be manufactured as finished products according to customer specifications.
Additional dimensions and custom-made products available upon request.
Depending on customer needs, profiles made by Aurubis BARS&PROFILES can be manufactured in different simple and complex shapes.
Aurubis BARS&PROFILES hollow profiles are particularly suitable for processing in induction systems and generators, and can be produced in different versions.
Furthermore, Aurubis BARS&PROFILES fins in simple as well as complex versions are ideally suited for the manufacture of commutators. A variety of finished products can be manufactured according to customer requirements.
All dimensions and profile geometries are available upon request.
Copper content and materials
In addition to the standard materials listed here, developments of CuAg0.01 to CuAg0.1 as well as other materials are possible upon request.
| Available materials |
| Cu-ETP |
| CuAg0,04 |
| CuAg0,1 |
| CuAg0,2 |
| Cu-HCP |
| CuAgP |
